Highly 2.4GHz 5.8GHz 50-100W Vehicle Mounted Counter Fpv System with High Gain Antenna Product overview 1. With high gain magnet antenna, can be mounted on the roof of the car. 2. Good cooling system, work continuously. 3. Stable capability, cost-effective choice. 4. Output power 100w make high jamming range. Parameters Product name 2-Band 2.4GHz 5.8GHz Vehicle Mounted Counter FPV System With High Gain Antenna To Against Drones Frequency Range 2.4GHz 5.8GHz(Support Custom

Product overview 1. With high gain magnet antenna, can be mounted on the roof of the car. 2. Good cooling system, work continuously. 3. Stable capability, cost-effective choice. 4. Output power 100w make high jamming range. Parameters Product name 2-Band 433mhz +900mhz Vehicle Mounted Counter FPV System With High Gain Antenna To Against Drones Frequency Range 433mhz +900mhz(Support Custom frequency from 300MHz-6000MHz Power 50-100W Product Size 320*210*90mm Material Aluminum

Product Parameters 428-438MHz 50W anti drone module for anti drone system Power and Frequnecy support Customzation form 90MHZ- 6700mhz, 10W,20W,30W, 40W, 50w,100W,150W,200W --GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module. --The power amplifier uses domestic core key components and can operate

Lead time Quantity(PCS)

50W GaN Anti-Drone RF Module 200-300MHz 47dBm Power Amplifier Key Features High-power 50W GaN RF module for anti-drone systems Frequency range: 200-300MHz (customizable from 10MHz to 6700MHz) Maximum output power: 47dBm Working efficiency: 60% Compact size: 37.3*112*19.5mm (excluding SMA connector) Operational temperature range: -10C to +55C Technical Specifications Parameter Value Working Frequency 200-300MHz (customizable 10-6700MHz) Output Power 50W (customizable 10W

Product overview 1.4G 1420-1450MHZ 30W module anti-drone module Power and Frequnecy support Customzation form 380MHZ- 5.8g, 10W,20W,30W, 40W, 50w,100W --The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the modul Parameters Frequency 1.4G 1420-1450MHZ Gain 45dBm Size 125*60*20mm Power 30W Power Flatness 1-1.5dB Supply Current 2.4A Operating Temperature --20~

High-Power 80W GaN RF Power Amplifier UAV Wideband Interference Module Product Specifications Customization Customization From 10 To 6700MHZ,10-200W Frequency And Power 400-3000MHZ 80W Gain 49dBm Dimensions 133.8*51.3*22.5MM Operating Voltage 24-32 V Operating Ambient Temperature -10+55 Highlight FPV Anti-Drone Module, 80W Anti-Drone Module, DJI Anti-Drone Module Product Description High Power GaN RF Power Amplifier 80W | 400 -3000MHz Wideband Interference Module |

1.2G anti-drone module 30W Power and Frequnecy support Customzation form 90MHZ- 5.8g, 10W,20W,30W, 40W, 50w,100W The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module. Product Specifications Place of Origin Guangdong, China Brand Name LDSK Place of Origin Guangdong, China Product Name RF power amplifier module(GaN) Frequency 1160-1270/1200-1300/1100

Key Word Place of Origin Guangdong, China Brand Name LDSK Place of Origin Guangdong, China Product name RF power amplifier module(GaN) Frequency 720-1020MHz Out power 30W Frequency and Power Customization Support Max Gain 45 dBm Voltage 24-32V Product Size 29.7*131*15.5mm Product Weight 136 g Lead time Quantity(PCS)
