LDK-DX-02B4 Multi-Channel GNSS Spoofing Board with Intelligent Power Management and Rapid Cold Start for Anti-UAV Navigation Simulation

Name: LDK-DX-02B4 Multi-Channel GNSS Spoofing Board with Intelligent Power Management and Rapid Cold Start for Anti-UAV Navigation Simulation
Brand: Shenzhen Ladasky Technology Co.，Ltd
SKU: LDK-DX-02B4
Price: 8571 USD
Availability: InStock

Brand Name:	LDSK
Model Number:	LDK-DX-02B4
MOQ:	1
Price:	$8571
Delivery Time:	3-7 workdays
Payment Terms:	D/A,D/P,T/T,Western Union,,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Guangdong, China

Supported Systems:

BDS, GPS, GLONASS, Galileo, QZSS

RF Output Channels:

4 Independent Channels

Output Power Per Band:

≥ -20 DBm

Power Adjustment Range:

80 DB

Power Resolution:

0.25 DB

Cold Start Time:

≤ 60 S

Input Voltage:

DC 10-36V

Highlight:

FPV Anti-Drone Module, Anti-Drone Module, DJI Anti-Drone Module

Packaging Details:

Box

Supply Ability:

50000 pcs per month

Highlight:

Multi-Channel GNSS Spoofing Board

Intelligent Power Management Anti-UAV Navigation Simulation System

Rapid Cold Start GaN Module

Product Description

LDK-DX-02B4 Multi-Channel GNSS Spoofing Board

Intelligent Anti-UAV Navigation Simulation System designed for comprehensive drone countermeasure operations.

Key Advantages

Four independent RF output channels for simultaneous multi-system operation
Comprehensive coverage of BDS, GPS, GLONASS, Galileo, and QZSS navigation systems
Intelligent power management with 80dB dynamic range and 0.25dB resolution
Ephemeris download and injection capability for operation in signal-denied environments
Rapid cold start: operational readiness within 60 seconds
Wide input voltage range (DC 10-36V) compatible with various power systems

Core Capabilities

Complete GNSS Coverage: Simulates BDS B1, GPS L1/L2, GLONASS L1/L2, Galileo E1, and QZSS L1 signals
Precision Drone Control: Enables forced landing, directional expulsion, flight path guidance, and no-fly zone implementation
Adaptive Power Control: Manual/automatic power adjustment with fine 0.25dB resolution for optimal range configuration
System Integration: Compatible with radar and auxiliary devices for coordinated drone landing operations
Developer-Friendly: Standard interfaces and protocols support customization and secondary development

Technical Specifications

Parameter	Specification
Supported Systems	BDS, GPS, GLONASS, Galileo, QZSS
RF Output Channels	4 independent channels
Output Power per Band	≥ -20 dBm
Power Adjustment Range	80 dB
Power Resolution	0.25 dB
Cold Start Time	≤ 60 seconds
Operating Temperature	-40°C to +70°C
Storage Temperature	-45°C to +85°C
Input Voltage	DC 10-36V
Power Consumption	< 18W
Dimensions (LWH)	210 * 200.4 * 32 mm

Interface Configuration

No.	Interface Description	Type	Function
1-4	Signal Transmission	SMA	Navigation spoofing signal output (4 channels)
5	Signal Reception	SMA	GNSS signal reception with 5V power supply
6	Ethernet Interface	RJ45	Control and debugging interface
7	Board Power Input	3P Terminal	DC 10-36V main power supply
8	Amplifier Control	2P Terminal	Power amplifier switching control

Application Areas

Critical infrastructure protection for oil refineries, power plants, and chemical facilities
Law enforcement and border security drone countermeasure operations
High-security event protection and sensitive site defense systems
Drone testing, training, and signal analysis platforms
Precision drone guidance and cooperative landing applications

Performance Features

Parallel Multi-Channel Operation: Simultaneous simulation of complex multi-target scenarios
Fine Power Control: 0.25dB resolution enables precise signal strength management
Environmental Robustness: Operates reliably from -40°C to +70°C in challenging conditions
Rapid Integration: Standard interfaces facilitate quick deployment in existing security systems
Offline Capability: Ephemeris injection allows operation without live satellite signals

Lead Time

Quantity (PCS)	Lead Time (Days)
<100pcs	7
<500pcs	10
500-1000pcs	12
>1000pcs	To be negotiated

Customization Options

Item	MOQ (PCS)
Logo	1
Frequency	1
Power	1
Packing	1

Packing & Delivery

Selling Units	Single item
Single Package Size	20105 cm
Single Gross Weight	0.2kg
Package Type	Each piece is individually packed into a bag and then packed into a carton

About Manufacturer

Shenzhen Ladasky Technology Co., Ltd. is a national high-tech enterprise specializing in advanced technologies for UAV defense and low-altitude security systems. We focus on RF sensing, signal analysis, and active interference solutions. Our product portfolio includes UAV detection modules, RF suppression units, and navigation signal simulation systems. Ladasky is committed to delivering precise, efficient, and intelligent low-altitude protection solutions. Our systems have been widely applied in government agencies, public security, and critical infrastructure protection. Driven by innovation, we are dedicated to building industry-leading UAV control and management technology platforms.

Frequently Asked Questions

Why Choose Us?
We have professional knowledge, sincere service, patient reply, and excellent team that provides a comfortable buying experience.

Order Process

Send products you're interested in
We provide detailed information and quotations
Consult any questions about our products
Confirm order and receive payment information
Receive product confirmation photos and tracking number
Provide feedback after receiving goods
