6GHz Fixed Drone Detector RF Spectrum Analyzer 10km Range
| Place of Origin | Guangdong, China |
|---|---|
| Brand Name | LDSK |
| Model Number | LDSKXM |
| Minimum Order Quantity | 1 piece |
| Price | $23500-$27000 |
| Packaging Details | 590mm (L) × 490mm (W) × 270mm (H) 20kg |
| Delivery Time | 5-7workdays |
| Payment Terms | D/A,D/P,T/T,Western Union,MoneyGram， Paypal |
| Supply Ability | 500pcs per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Frequency | 100MHz～6GHz Fixed Detection Band, Optimized For UAV And FPV Drone Signals. | Long Detection Range | Up To 10 Km (range Varies With Environmental Conditions And UAV Type). |
|---|---|---|---|
| FPV & UAV Detection | Captures FPV And UAV Signals For Security And Surveillance Purposes. | Autonomous Operation | Can Run Continuously With Minimal Human Intervention, Ideal For Fixed Installation. |
| High Precision | Accurate Detection Of UAV Location, Altitude, Speed, And Trajectory. | Versatile Applications | Border Security, Critical Infrastructure, Military, And Commercial Protection. |
| Easy Integration | Compatible With Additional Jamming Modules And Multi-device Networks For Enhanced Coverage. | ||
| Highlight | 10KM stationary drone detector,full band RF drone detector,fixed drone spectrum detector |
||
You can tick the products you need and communicate with us in the message board.
Product Description
6GHz Fixed Drone Detector RF Spectrum Analyzer with 10km Range
Key Attributes
| Attribute | Value |
|---|---|
| Working Mode | RF Sensing |
| Detection Frequency Band | 100MHz～6GHz |
| Detection Mode | 360° Passive Detection |
| Range | 1～10km |
| Drone Module Location | Multi-station network with TDOA multi-model precise positioning and trajectory tracking |
Product Overview
The UAV Detector is a portable monitoring system integrating software and hardware. Through advanced signal analysis, it provides comprehensive drone detection including:
- Detection range, serial number, and model identification
- Position, speed, height, and altitude tracking
- Take-off point, return point, and flight trajectory mapping
- Pilot position detection
Performance Parameters
| No. | Project | Parameter |
|---|---|---|
| 1 | Detection frequency band | 100MHz～6GHz |
| 2 | Detection distance | 1～10km |
| 3 | Number of detection targets | ≥5 simultaneously |
| 4 | Detection mode | 360° Passive detection |
| 8 | Positioning accuracy | ≤10m |
Technical Capabilities
- Drone monitoring: Comprehensive UAV data collection including serial numbers, positions, and flight paths
- Unique ID identification: Confirms drone identity through serial number verification
- UAV positioning: Real-time display of position, azimuth, and distance information
- Pilot positioning: Detection and display of remote control operator location
- Multi-target tracking: Simultaneous tracking of multiple drone trajectories
- Security features: Black/white list differentiation and intrusion alarms
- Data analysis: Flight trajectory playback and historical record preservation
- System integration: Network capability with multiple units and countermeasure devices
Key Features
Wide detection range: Identifies common drone brands including DJI, Autel, Fimi, and most market models
Long-range capability: Up to 10km detection in open environments
Passive operation: No electromagnetic emissions for environmentally friendly monitoring
24/7 protection: Continuous operation in all weather conditions with 360° coverage
Fixed installation: Durable outdoor design for permanent deployment
Customization Options
| Item | MOQ |
|---|---|
| Logo | 1 PC |
| Frequency | 1 PC |
| Power | 1 PC |
Production Lead Times
| Quantity | Lead Time |
|---|---|
| <10pcs | 7 Days |
| <50pcs | 15 Days |
| 50-100pcs | 15-20 Days |
Contact Information
Email: jess@ladaskytech.com
Shenzhen Ladasky Technology Co., Ltd. specializes in counter-UAV systems, focusing on RF sensing, signal processing, and active jamming technologies for government and critical infrastructure protection.
