High-Gain 18dBi Horn Antenna with 50dB Cross Pol. Isolation and 29-17° H-Plane Beamwidth for UAV Detection and Radar
High-Gain 18dBi Horn Antenna with 50dB Cross Pol. Isolation and 29-17° H-Plane Beamwidth for UAV Detection and Radar
Basic Properties
Country Of Origin
Guangdong, China
Brand Name
LDSK
Trading Properties
MOQ
1 piece
Unit Price
$2285
Payment Method
D/A,D/P,T/T,Western Union,， Paypal
Supply Capacity
5000pcs per month
Product Summary
18dBi Horn Antenna 1-3GHz SMA-Female for Anti-Drone UAV Communication Product Specifications Attribute Value Frequency Range 1-3Ghz Gain 18 DBi VSWR 1.4 Typ. Polarization Linear Cross Pol. Isolation 50Typ. 3dB Beamwidth H-Plane: 29-17 Connector SMA-Female Finishing Paint Black Material Al Size 765...
Product Details
Highlight:
18dBi horn antenna SMA-Female
,high-gain directional antenna 1-3GHz
,wideband horn antenna anti-drone
Wide Frequency Range (2–8ghz):
Supports Multiple RF Bands For Drone Detection, Radar, And Spectrum Monitoring.
High Gain (18dbi)::
Provides Strong Directional Performance, Ensuring Precise Signal Targeting And Long-range Coverage.
Directional Radiation Pattern:
Ideal For Anti-drone And Counter-UAV Systems Requiring Focused Signal Transmission Or Reception.
Versatile Applications::
Perfect For Drone Defense Systems, EMC Testing, Radar Calibration, RF Measurement, And Research Labs.
Product Description
18dBi Horn Antenna 1-3GHz SMA-Female for Anti-Drone UAV Communication
Product Specifications
| Attribute | Value |
|---|---|
| Frequency Range | 1-3Ghz |
| Gain | 18 DBi |
| VSWR | 1.4 Typ. |
| Polarization | Linear |
| Cross Pol. Isolation | 50Typ. |
| 3dB Beamwidth | H-Plane: 29-17 |
| Connector | SMA-Female |
| Finishing | Paint Black |
| Material | Al |
| Size | 765.99*439.92*439.92mm |
| Weight | 7.415KG |
Product Highlights
- UAV Communication Fiberglass Omni Antenna
- Uav Defense Antenna 60cm
- Anti Uav Fiberglass Omni Antenna
Detailed Specifications
| Parameters | Specifications | Units |
|---|---|---|
| Frequency Range | 1-3 | GHz |
| Gain | 18 Typ. | dBi |
| VSWR | 1.4 Typ. | |
| Polarization | Linear | |
| Cross Pol. Isolation | 50Typ. | dB |
| 3dB Beamwidth | E-Plane: 29-12 H-Plane: 29-17 |
deg |
