Product Details:
Payment & Shipping Terms:
|
Customization: | Customization From 10 To 6700MHZ,10-200W | Frequency And Power: | 100-150mhz 50W |
---|---|---|---|
Gain: | 47dBm | Voltage: | 24-32V |
Working Efficiency: | >60% | Size: | 37.3*112*19.5mm |
Highlight: | Anti Fpv Power Amplifier Module, Anti Usv Power Amplifier Module | ||
Highlight: | 50W RF power amplifier module,Anti drone RF amplifier,100-150MHz power amplifier module |
Item name | Technical parameters |
Working frequency | 100-150MHz (Support customization from 10 to 6700MHZ ) |
Power | 50W (Support customization from 10W to 200MHZ ) |
Supply Voltage | DC 24-32V |
Max Output Power | 47 dBm |
Working Efficiency | ≥60% |
Passband Riplpe | ≤2dB |
Operating Temperature | -10~+55ºC |
Power supply requirements | ≥3.7A |
RF Connector | SMA |
Size | 37.3*112*19.5mm (Excluding SMA) |
Weight | 186g |
Connect line red | DC28-30V |
Connect line black | GND |
Connect line white | ENABLE |
Quantity(PCS) | <100pcs | <500 | 500-1000 | >1000 |
Lead time(Days) | 3 | 3-5 | 7-12 | To be negotiated |
Item | Logo | Frequency | Power | Packing |
MOQ(PCS) | 1 | 1 | 1 | 1 |
Company profile
Selling Units: | Single item |
Single package size: | 20X10X5 cm |
Single gross weight: | 0.2kg |
Package Type: | Each piece is individually packed into a bag and then packed into a carton. |
