50W-100W Anti FPV Lora Module 700-1000MHz Frequency Power Amplifier Module

Name: 50W-100W Anti FPV Lora Module 700-1000MHz Frequency Power Amplifier Module
Brand: Shenzhen Ladasky Technology Co.，Ltd
SKU: 4000-8000mhz 100w
Price: 2600.00 USD
Availability: InStock

Brand Name:	Ladasky
Model Number:	4000-8000mhz 100w
MOQ:	1pcs
Price:	$2400-2800
Delivery Time:	1-3 workdays
Payment Terms:	D/A,D/P,T/T,Western Union， Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Work Frequency Band:

4000-8000mhz 100w

Power:

100W

Operating Voltage:

28V-32V

Current:

RF Interface:

SMA Input, N Output

Size:

170×78×24.5mm

Temperature:

40℃～+55℃

Supply Ability:

50000pcs per month

Highlight:

100W Anti FPV Lora Module

Fpv Counter Power Amplifier Module

Lora Anti FPV Module

Product Description

700-1000MHz 100W 50W-100W Optional Lora Anti FPV Digital Modulation Power Amplifier Module

Product Description

Specification

1.Overview

700-1000Mhz/720-1020Mhz 100W

The traversing machine countermeasures digital modulation power amplifier module is a traversing machine countermeasure module that includes a countermeasure signal source and a power amplifier. It can be used directly after connecting to the antenna.

The module uses an FPGA logic chip as the main control, combined with the excellent frequency stability of the frequency-locked VCO to create an anti-travel machine digital modulation signal plus power amplifier module.

The digital modulation signal is generated internally by the FPGA, modulated on the carrier with the VCO as the oscillation
frequency, and is emitted through the countermeasures process of the antenna.

The module uses a 50Ω SMA radio frequency interface output, which can be easily connected to the SMA interface power amplifier module.

2.Performance Characteristics

1)Supported frequency: 300-1200MHz, 2.4GHz, etc.
2)Output power: 100W 30-100W optional
3)Small size, convenient for user integration
4)Industrial-grade application design, using industrial-grade chips, suitable for industrial-grade applications
5)Can effectively and accurately counter FPV drones

3.Basic functions

Set the digital modulation signal parameters of the counter source according to the remote control frequency band of the FPV , and modulate to the customized frequency band. The modulated counter signal is filtered through the RF front stage and output to the antenna through power amplification, forming the wireless signal of the remote control signal of the counter crossing machine.

4.Application instructions

The module power source is 24~28V, the module design is small for machine integration; the RF output SMA port of digital modulation amplifier counter module is impedance 50 Ω interface, the output transmission antenna, and the interface impedance must be consistent.The integrated working temperature should not exceed the working temperature of the module, and ensure good heat dissipation.

5.Use frequency range

The customized frequency band corresponds to the remote control signal of the F P V DR O N E , and the countermeasures over the frequency range has no effect.

6.Interference distance and output power configurati

The interference distance is related to the output power of the power amplifier and the transmitting antenna. The greater the antenna gain, the greater the output power, and the farther the counter distance. At the same time, the best effect is in the unshielding environment, that is, no shielding between the counter signal and the FPV drone

Item	Parameters	Remark
Operating Voltage	24-28V
Output Power	100w, 300w-100w optional
Frequency	300~1200MHz,2.4GHz ISM	Full frequency band can be customized
Current	8A-10A
RF interface	SMA	RF output
RF interface impedance	50Ω
Size	1565424mm
Temperature	-40℃+80℃	Industrial grade

Packing & Delivery

Company Profile

Ladasky Technology Co.,Ltd

Shenzhen Ladasky Technology Co.,LTD. specializes incutting-edge anti-drone modules and integrated solutions. With our own state-of-the-art factory, we offer highly competitivepricing and exceptional product quality, garnering widespread acclaim from our international clientele.

FAQ

1.Why Choose us?

We have professional knowledge, sincere service, patient reply, and excellent team. Can give you a comfortable buying experience.

2.What is the process of placing an order?
First, you send products you like.
Second, we send information details and quotations.
Third, you can consult any questions about our products.
Fourth, confirm the order, we will send PI, payment link.
Fifth, after the goods are packaged, we will send pictures to confirm the products, and send you the express tracking number.
Sixth, after receiving the goods, you are welcome to give us product evaluations.
