PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A

PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A
PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A

Large Image :  PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A

Product Details:
Place of Origin: Guangdong, China
Brand Name: LDSK
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: $90-$110 1-1000pcs
Packaging Details: 20*10*5cm, 0.5KG
Delivery Time: 1-3 workdays
Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram， Paypal
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Model NO.: LDSK-810-920MHz Max Output Power: 50W
Working Efficiency: More Than 52% Peak Gain: 47dBi
Working Temperature: -10~+55 Degree Celcius Origin: Guangdong
Supply Ability: 50000PCS/Month Frequency: 810-920MHz
Application: All Working Voltage: 24-32V
Required Power Supply: More Than 3.7A Samples: US$ 110/Piece
Customization: Available | Customized Request
Highlight:

50W GaN Anti Drone Module

,

900MHz GaN Anti Drone Module

,

PA Module GaN Anti Drone Module

Product Parameters

--GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module.

--The power amplifier uses domestic core key components and can operate normally at temperatures of -10~+55°C.

--This document stipulates the radio frequency and monitoring technical indicators of the 810-920MHz 50W power amplifier module, the definition of each port of the module, the appearance and structure of the module, etc.

--This document applies to all aspects of product design, verification, production and quality inspection of the 810-920MHz 50W power amplifier module.
Item name Technical parameters
Working frequency 810-920MHz
Power 50W
Supply Voltage DC 24-32V
Max Output Power 47 dBm
Working Efficiency ≥60%
Passband Riplpe ≤2dB
Weight 105 g
Operating Temperature -10~+55ºC
Power supply requirements ≥3.7A
RF Connector SMA
Weight 160g
Size 37.3*112*19.5mm (Excluding SMA)
Connect line red DC28-30V
Connect line black GND
Connect line white ENABLE
Product Description

PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A 0

PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A 1

PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A 2



Lead time

Quantity(PCS) <100pcs <500 500-1000 >1000
Lead time(Days) 3 3-5 7-12 To be negotiated


Customization

Item Logo Frequency Power Packing
MOQ(PCS) 1 1 1 1




Company profile

PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A 3

Shenzhen ladasky technology Co,.LTD, specializing in the field of advanced technology. Our company is located in the vibrant city of Shenzhen, known as a hub of innovation and technology in China.



Our main products include RF module and anti FPV, which are designed with cutting-edge technology and strict quality control to meet the diverse needs of our customers. The RF module offers high-performance and stable signal transmission, enabling seamless communication in various applications. The anti FPV solution provides effective protection against unauthorized interference and ensures the security and privacy of video transmission.



We pride ourselves on our strong R&D team, composed of experts and engineers with rich experience and professional knowledge in the field. They are constantly exploring and innovating to bring forth new and improved products that stay ahead of the market trends.

Our manufacturing facilities are equipped with state-of-the-art machinery and adhere to international quality standards. This ensures that every product leaving our factory is of the highest quality and reliability.




Packing and Delivery
Selling Units: Single item
Single package size: 20X10X5 cm
Single gross weight: 0.2kg
Package Type: Each piece is individually packed into a bag and then packed into a carton.

PA Module 810-920mhz Anti Drone Module 900MHz 50W GaN Anti-Autel Drone Defense Module Required Power Supply More Than 3.7A 4
