Anti Drone Module
Created with Pixso. Module 433MHz 20W Anti Drone Detection for Defense System 10W 20W 30W Optional
Module 433MHz 20W Anti Drone Detection for Defense System 10W 20W 30W Optional
  • name
  • name
  • name
  • name
  • name

Module 433MHz 20W Anti Drone Detection for Defense System 10W 20W 30W Optional

Brand Name: LDSK
MOQ: 1 piece
Delivery Time: 1-3 workdays
Payment Terms: D/A, D/P, T/T, Western Union， Paypal
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Trademark:
LDSK
Frequency:
433mhz
Power:
10W 20W 30W 50W 100W Optional
Size:
29.7*131*15.5mm
Customization:
Available | Customized Request
Supply Ability:
50000PCS/Month
Supply Ability:
5000pcs per month
Highlight:

20W Anti Drone Detection Module

,

30W Anti Drone Detection Module

,

10W Anti Drone Detection Module

Product Description
Product Description

Module 433MHz 20W Anti Drone Detection for Defense System 10W 20W 30W Optional 0

Module 433MHz 20W Anti Drone Detection for Defense System 10W 20W 30W Optional 1




Product Parameters
Product name Anti-drone module Power amplifier module
Frequency 420-450Mhz,830-930Mhz,1170-1280Mhz, 1350-1450Mhz,1550-1620Mhz, 2400-2500Mhz, 5150-5350Mhz, 5725-5850Mzh Optional
Power 10W 20W 30W 50W 100W Optional
Supply Voltage DC 24-32V
Power Flatness 1-1.5dB
Input/Output VSWR 1.5dB
Supply Current 2.5-3A
Product Size 29.7*131*15.5mm
Product Weight P136g
Operating Temperature 20ºC-80ºC
Connect line RED:DC28-30V
BLACK:GND
WHITE:ENABLE



Packing & Delivery
Module 433MHz 20W Anti Drone Detection for Defense System 10W 20W 30W Optional 2
Company Profile

Module 433MHz 20W Anti Drone Detection for Defense System 10W 20W 30W Optional 3



FAQ

1.Why Choose us?

We have professional knowledge, sincere service, patient reply, and excellent team. Can give you a comfortable buying experience.

2.What is the process of placing an order?
First, you send products you like.
Second, we send information details and quotations.
Third, you can consult any questions about our products.
Fourth, confirm the order, we will send PI, payment link.
Fifth, after the goods are packaged, we will send pictures to confirm the products, and send you the express tracking number.
Sixth, after receiving the goods, you are welcome to give us product evaluations.
