Multi-System GNSS Deception Solution for Professional Drone Control Product Overview The LDK-AY-22 GNSS Deception Module is an intelligent counter-drone solution engineered to take control of UAV navigation by simulating authentic satellite positioning signals . Unlike traditional jamming systems, LDK-AY-22 misleads drones rather than blocking signals. By broadcasting precisely generated GNSS signals, it causes UAVs to calculate false positions, enabling controlled outcomes

Product Parameters 200-300MHz 50W anti drone module for anti drone system Power and Frequnecy support Customzation form 90MHZ- 6700mhz, 10W,20W,30W, 40W, 50w,100W,150W,200W --GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module. --The power amplifier uses domestic core key components and can operate

Product Parameters 1.2GHz 50W anti drone module for anti drone system Power and Frequnecy support Customzation form 90MHZ- 6700mhz, 10W,20W,30W, 40W, 50w,100W,150W,200W --GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module. --The power amplifier uses domestic core key components and can operate normally at

LDKF08 Handheld Individual FPV Jamming Device Advanced Drone Countermeasure Technology Professional dual-band portable FPV jamming system designed for defense and security applications. This handheld device effectively disrupts unauthorized drone operations through targeted signal interference. Key Features High-Efficiency Jamming: Advanced signal jamming technology transmits interference signals on FPV drone frequencies, disrupting communication, navigation, and video links

Product Parameters GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module. The power amplifier uses domestic core key components and can operate normally at temperatures of -10~+55C. This document stipulates the radio frequency and monitoring technical indicators of the 600-700MHz 50W power amplifier module,

Product Parameters GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module. The power amplifier uses domestic core key components and can operate normally at temperatures of -10~+55C. This document stipulates the radio frequency and monitoring technical indicators of the 600-700MHz 50W power amplifier module,

Product Description Product Parameters Product name Anti-drone module Power amplifier module Frequency 420-450Mhz,830-930Mhz,1170-1280Mhz, 1350-1450Mhz,1550-1620Mhz, 2400-2500Mhz, 5150-5350Mhz, 5725-5850Mzh Optional Power 10W 20W 30W 50W 100W Optional Supply Voltage DC 24-32V Power Flatness 1-1.5dB Input/Output VSWR 1.5dB Supply Current 2.5-3A Product Size 29.7*131*15.5mm Product Weight P136g Operating Temperature 20C-80C Connect line RED:DC28-30V BLACK:GND WHITE:ENABLE

TTSK Power Dds Integrated Module Walkie-Talkie 300-2400MHz Dds Noise Source Signal Module Parameters Test Item Parameter Unit Remarks working voltage 28 V 24-30V transfer efficiency 42% % @100W typical Controlled output power 10W~100W W The Software sets the power level The ALC power adjustment range 30 dB Pressure control attenuation gain 501.0 dB Intra-band fluctuations 2.5 dB peak-to-peak value stray launch Work within the belt -15dBm/1MHz dBm Center frequency plus CW

Parameters Frequency 840-920MHz 8dbi 1100-1300MHz 12dbi (410-485MHz 7dbi) 1560-1620MHz 12dbi 2400-2500MHz 14.5dbi 5150-5350MHz 17dbi 5700-5900MHz 17dbi VSWR 1.5 Maximum input power(W) 50W (100W is customized not standard ) Input connector type N*J or customized (Wire length customized too ) Lightning Protection DC Ground Dimensionsmm(Height/Width/Depth) 260*260*40mm Antenna weight(kg) 885g Rated Wind Velocity(m/s) 60m/s Operational Humidity(%) 10- 95 Radome Color Black color
