300-6300MHz 30W PA Module for Anti-Drone System
LDK-300-6300MHz 30W PA Module Power Amplifier for portable anti-drone RF applications.
This module operates without an internal signal source, supporting external signal input while maintaining stable 100W output power.
This series of GaN power amplifier modules utilizes advanced gallium nitride technology, featuring high efficiency, high gain, wide bandwidth, and excellent thermal stability. The compact design supports multi-band coverage and multiple power levels, offering strong compatibility and easy integration into various end devices.
Technical Specifications
|
Test Item |
Index |
Unit |
Remarks |
|
|
Frequency Range |
300-6300 |
MHz |
|
|
|
Operating Voltage |
28 |
V |
24 - 32V |
|
|
Maximum Output Power |
30-50 |
W |
30W@≤4.7A Typical values |
|
|
Amplifier Efficiency |
25 |
% |
@30W Typical values |
|
|
Maximum Gain |
38 |
dB |
Maximum power gain |
|
|
Small Signal Gain |
45-50 |
dB |
|
|
|
Gain Flatness |
≤7 |
dB |
|
|
|
Standard Input Power |
+7 |
dBm |
|
|
|
Maximum Non-Damaging Power |
≤13 |
dBm |
|
|
|
Input and Output Port Standing Wave Ratio |
≤2.5 |
|
No power, network test |
|
|
High and Low Temperature Test |
Operating Environment Temp |
-30～+55℃ |
℃ |
|
|
Power Stability |
±1.5 @-30℃～+55℃ |
dB |
|
|
|
Power Supply Req. |
≥6.5A@+28V DC |
|
30W CW output |
|
|
Power Interface |
Feedthrough Capacitors |
|
|
|
|
PA Enable |
Feedthrough Capacitors |
|
Turn on at high level, turn off at low level(High 3.3-5V) |
|
|
RF Input and Output Connector |
SMA |
|
SMA female |
|
|
Dimensions |
130*62.9*24.5 |
mm |
|
|
|
Weight |
360 |
g |
|
|
|
Mounting Holes |
125.3*57.7 |
mm |
M3.0*4 |
|
Product Details
Product Application
Company Profile
FAQ
A1:It is the full band cover from 300-6300MHZ
A2: 1PCS.
A3: It uses GaN (Gallium Nitride) technology for high efficiency and reliability.
A4: It supports both forced air cooling and conductive heat sink cooling via the bottom-mounted heat sink.
