LDK-DGA1-01 Fixed Drone Detector 70-6000MHz UAV Detection System With Location Function

Product Overview

Why choose LDK-DGA1-01--Product Features

70 MHz – 6 GHz Full-Band Spectrum Detection:Covers all known drone communication protocols, including OcuSync (O2 / O3 / O3+ / O4 / O4+), RF flight control, and FPV analog video transmission. No drone goes undetected.

Long-Range Detection up to 10 km:Achieves ≥10 km detection range in line-of-sight environments (DID protocol: O2/O4 ≥10 km; O3/O3+ ≥5 km; RID ≥2 km). FPV analog video signals detected up to 1.5 km with real-time video viewing capability.

360° Direction Finding & Precision Geolocation:Horizontal detection angle up to 360°. 2.4 / 5 GHz direction-finding accuracy ≤±15° (RMS). Provides real-time drone distance, altitude, speed, latitude/longitude (accurate to 1 meter), model, SN code, take-off point, return point, and flight trajectory.

Unattended 24/7 Intelligent Operation: Executes preset defense plans automatically in all weather conditions. Upon detection, the system rapidly coordinates with external suppression devices for beyond-perimeter mitigation — fully automated or manually controlled via the cloud platform.

Advanced Cloud Platform: Features high-definition GIS mapping, GPS positioning, automatic north calibration, black/whitelist management, intrusion log playback & statistical reporting, and real-time device status monitoring (online / standby / offline / abnormal).

Signal Intelligence & AI Learning: Built-in drone signal collection function captures unknown RF signatures, automatically extracts parameters, and adds them to the threat database after manual confirmation. Optional AI autonomous learning module available for automatic model database expansion.

Ruggedized for Extreme Environments: Aviation-grade aluminum alloy enclosure rated IP66. Operating temperature: -40°C to +60°C. Designed for permanent outdoor deployment in harsh climates.

Product Desciption

Q7: What are the core functions of the cloud platform?

A7: The cloud platform provides: Unattended/Manual Dual-Mode Control,Blacklist/Whitelist Management, High-Definition GIS Map Display (Device Deployment Point, Surrounding Environment),  Log Playback and Statistical Reports (Angle, Time, Frequency), GPS Positioning and Automatic North Calibration, Unknown Signal Acquisition and Feature Database Expansion, Device Status Monitoring (Online/Standby/Power Failure/Abnormal), FPV Analog Video Storage and Playback

Q8: What if an unknown drone model is detected?

A8: The device has a built-in signal acquisition and learning function, which can automatically acquire signals from unknown drones and extract parameters. After manual confirmation, these parameters are added to the drone feature database. Additionally, an optional AI self-learning module can be added to automatically include new models in the database.

Q9: What are the physical specifications and weight of the device?

A: The device weighs ≤16kg and measures 400mm in diameter × 531mm in height. Its compact structure makes it suitable for fixed installation on rooftops, towers, tripods, or dedicated poles.

Q10: Does it support customization?

A10: Yes. Tatusky can provide customized intelligent solutions based on customers' specific needs (such as specific frequency bands, protocols, linkage methods, platform integration, etc.) to achieve the best protection effect.
